SSF - 63 HYPERCAR PROJECT

The SSF-63 is a self-branded LMP2 hypercar for Le Mans 24H racing.  My focus of this project is on the appearance design, CAD design, and aero analysis of the car.


TIME:  2023 FALL

DURATION:  7 WEEKS

SOFTWARE


DESIGN KEYWORDS

AERODYNAMIC

LIGHTWEIGHT

NEED FOR SPEED

AERODYNAMIC


LIGHTWEIGHT


NEED FOR SPEED


ORTHOGRAPHY OF SSF-63


Height: 1090mm

Wheelbase: 2300mm

Height: 1290mm


Width: 1885mm

Wheelbase: 2300mm

Overall Length: 4600mm

Width: 1885mm

Height: 1290mm

Front tire: 265/35/ZR 20

BENCHMARK

Overall Length: 4600mm

Rear tire: 325/30/ZR 21

CAD MODEL

PERIOD OF TIME: 55H

5f2fb6271c4202ab526878d2cb435e1_edited.j
96f924f7b51750b6eec8216b5873f83_edited.j
8af4f18ea9e8cf6d1f8fcb1c5a1d207_edited.j
123a7a05a4f873928ab2afec5b0531f_edited.j

INTRODUCING SSF-63

SSF-63 PHEV LMP2 HYPERCAR

SSF-63 is a hybrid Le Mans LMP2 division hypercar integrated with 2 powerful electric motors and a v6 mid-engine design.

a9be9758908dd1051269e35f1dc4b59_edited.j
782275395472487134_edited_edited_edited.
d0dce8ba3db517ab4cfeba230d91ee9_edited.j
0436b12a3450f5f144bef431afecb40_edited.j
9568cc52d84973839f660a4fa269aad_edited.j
b46f6b70f11d04a6f65f7aa2599b78c_edited.j

MINIMIZE THE DRAG

Through the Venturi effect, I designed a choked area to create a low-pressure zone with high air velocity which creates a suction area. By preventing the air flow separation, the front wing also gives multiple vortex generators which could help attach the flow, reducing the wake and drag force.  When the high-pressure zone from outside meets the low pressure, it generates vortices that follow the shape of the car.


DOWNFORCE BALANCE

The massive rear wing of the back produces a lot of downforce which lets the rear tires attach to the ground. The DRS system plays a crucial role in the straight-line to degenerate downforce. The endplates of the rear wing help reduce the turbulence and the air drag of the wing. I designed the rear wing by tilting it downward, which makes the vortices smaller and decreases vortex drag.

SUSPENSION

The front suspension of the car is a push rod and the rear is pull, it allows essential components to be moved out of direct airflow, closer to the center of gravity, and allow the center of gravity to be lowered, thereby creating a more efficient distribution of weight and management of body roll.
